Meta-Braze Range of Silver Brazing Alloys

The Meta-Braze range of silver brazing alloys can be used to join most of the common engineering metals used in industry such as copper, copper alloys (brass, bronze, nickel silver etc.), nickel alloys, mild or carbon steel, stainless steel and tungsten carbide. They are not suitable for aluminium or magnesium alloys.

Key ProductsAgCuZnSnSiMelting Range °CAWS A5.8EN1044:1999ISO 17672:2016Product Info
Silver Brazing Alloys - High Silver Content with Low Melting Temperatures and Free Flowing Characteristics
Meta-Braze 060602614--695-730-AG202-View product info

Meta-Braze 060

Meta-Braze 060 is not a common alloy, it is designed for use on cupro-nickel and nickel alloys where stress cracking might be an issue.

Product Forms

  • rods
  • wire
×
Meta-Braze 1565622175-620-655BAg-7AG102Ag 156View product info

Meta-Braze 156

Meta-Braze 156 conforms to AWS BAg-7 and combines low brazing temperatures with a short melting range making it free flowing and easy to use.

In addition to the product forms shown here Meta-Braze 156 is also available as a Meta-Braze Advanced product with flux incorporated into the product, in a channel or central core, for repeatable and controlled brazing.

Product Forms

  • rods
  • wire
  • powder
  • foil
  • strip
  • rings
  • braze-paste

Downloads

×
Meta-Braze 1555521222-630-660-AG103Ag 155View product info

Meta-Braze 155

Meta-Braze 155 is the most widely used brazing alloy combining low brazing temperatures with a short melting range making it free flowing and easy to use.

Product Forms

  • rods
  • wire
  • powder
  • foil
  • strip
  • rings
  • braze-paste

Downloads

×
Meta-Braze 145452725.52.5-640-680-AG104Ag 145View product info

Meta-Braze 145

Meta-Braze 145 provides an alloy with silver content and properties that are between the high silver (55 / 56%) alloys and those with a medium level of silver (38 / 40%). Also suitable for brazing PCD below 750°C.

Product Forms

  • rods
  • wire
  • powder
  • foil
  • strip
  • rings
  • braze-paste
×
Meta-Braze 145 Si452725.32.50.2640-680--Ag 145 SiView product info

Meta-Braze 145 Si

Meta-Braze 145Si provides an alloy with silver content and properties that are between the high silver (55 / 56%) alloys and those with a medium level of silver (38 / 40%). The addition of silicon gives the alloy a smooth neat fillet meaning that brazed joints have an excellent appearance. Consequently this alloy has been used in decorative brass tube and pipe fittings.

Product Forms

  • rods
  • wire
  • rings
×
Silver Brazing Alloys - Medium and Low Silver Content with Medium Melting and Flow Characteristics
Meta-Braze 1404030282-650-710BAg-28AG105Ag 140View product info

Meta-Braze 140

Meta-Braze 140 is a popular general-purpose product with medium melt and flow characteristics. It is often used to make tube and pipe joints in a variety of brazing applications ranging from refrigeration and air-conditioning fittings to hydraulic or automotive parts.

Product Forms

  • rods
  • wire
  • foil
  • strip
  • rings
  • powder
  • braze-paste

Downloads

×
Meta-Braze 140 Si403027.820.2650-710--Ag 140 SiView product info

Meta-Braze 140 Si

Meta-Braze 140 Si is not a common alloy but could be used in applications where a medium temperature alloy is required with smooth flow characteristics provided by the silicon addition.

Product Forms

  • rods
  • wire
  • strip
  • rings
×
Meta-Braze 1383832282-650-720BAg-34-Ag 138View product info

Meta-Braze 138

Meta-Braze 138 provides a lower silver alternative to Meta-Braze 140 and conforms to BAg-34. Meta-Braze 138 is also available as a Meta-Braze Advanced product with flux incorporated into the product, in a channel or central core, for repeatable and controlled brazing.

Product Forms

  • rods
  • wire
  • powder
  • foil
  • strip
  • rings
  • braze-paste
×
Meta-Braze 1303036322-665-755-AG107Ag 130View product info

Meta-Braze 130

Meta-Braze 130 provides good gap filling properties and is used in applications where joint gaps are not tightly controlled.

Meta-Braze 130 is also available as a Meta-Braze Advanced product with flux incorporated into the product, in a channel or central core, for repeatable and controlled brazing.

Product Forms

  • rods
  • wire
  • powder
  • foil
  • strip
  • rings
  • braze-paste

Downloads

×
Meta-Braze 1252540332-680-760BAg-37AG108Ag 125View product info

Meta-Braze 125

Meta-Braze 125 is a low silver content alloy with a long melting range and 'sluggish' alloy flow making it useful for building up fillets on a joint. This alloy can be used for brazing of steel fittings where the joint gaps cannot be tightly controlled.

Product Forms

  • rods
  • wire
  • rings

Downloads

×
Meta-Braze 024244333--740-800---View product info

Meta-Braze 024

Meta-Braze 024 is an alloy that is approved for use by Rolls-Royce MSRR 9500/93. It is also used for step brazing operations in conjunction with Meta-Braze 155 where multiple joints need to be made in close proximity to each other, for example by model engineers making a steam boiler.

Product Forms

  • rods
  • wire
  • braze-paste
×
Meta-Braze 020204435.8-0.2690-810-AG206Ag 220View product info

Meta-Braze 020

Meta-Braze 020 is a higher melting point alloy sometimes used where a low cost alloy is required for brazing of steel components with wide or variable joint gaps. It produces large fillets and is a good gap filling alloy.×
