High purity palladium containing brazing alloys find use in a variety of applications including electronic components for imaging,aerospace, oil and gas and chemical. The Pd-Cu-Ag alloys in this range are often selected because they show good wetting on a variety of materials including Kovar and Mo-Mn seals. Also they have narrow melting ranges and can be produced in ultra pure V1 grademaking them suitable for brazing and step-brazing of complex metallised ceramics in electronic components. Palladium bearing alloys also exhibit good corrosion resistance and strength at elevated temperatures.
| Key Products | Pd | Ag | Cu | Ni | Other | Melting Range °C | AWS A5.8 | EN1044:1999 | ISO 17672:2016 | Product Info |
|---|---|---|---|---|---|---|---|---|---|---|
| Meta-Braze™ Pd 287 | 5 | 68.5 | 26.5 | - | - | 805-810 | BVAg-30 | PD106 | Pd 287 V1 | ViewMeta-Braze™ Pd 287Meta-Braze™ Pd 287 is a palladium-silver-copper brazing filler metal which is used in a wide range of applications including vacuum tube devices, electronic components and aerospace components. It can also be used to produce joints for moderately high (300-400°C) elevated temperature service conditions where it exhibits good oxidation resistance coupled with good elevated-temperature mechanical properties. Product Forms× |
| Meta-Braze™ Pd 388 | 10 | 67.5 | 22.5 | - | - | 830-860 | - | PD104 | Pd 388 V1 | ViewMeta-Braze™ Pd 388Meta-Braze™ Pd 388 is a palladium-silver-copper brazing filler metal which is used in a wide range of applications including vacuum tube devices and electronic components. It can also be used to produce joints for moderately high (300-400°C) elevated temperature service conditions where it exhibits good oxidation resistance coupled with good elevated-temperature mechanical properties. Product Forms× |
| Meta-Braze™ Pd 387 | 10 | 58 | 32 | - | - | 825-850 | BVAg-31 | PD105 | Pd 387 V1 | ViewMeta-Braze™ Pd 387Meta-Braze™ Pd 387 is a palladium-silver-copper brazing filler metal which is used in a wide range of applications including vacuum tube devices and electronic components. It can also be used to produce joints for moderately high (300-400°C) elevated temperature service conditions where it exhibits good oxidation resistance coupled with good elevated-temperature mechanical properties. Product Forms× |
| Meta-Braze™ Pd 481 | 15 | 65 | 20 | - | - | 850-900 | - | PD103 | Pd 481 V1 | ViewMeta-Braze™ Pd 481Meta-Braze™ Pd 481 is a palladium-silver-copper brazing filler metal which is used in a wide range of applications including vacuum tube devices and electronic components. It can also be used to produce joints for moderately high (300-400°C) elevated temperature service conditions where it exhibits good oxidation resistance coupled with good elevated-temperature mechanical properties. Product Forms× |
| Meta-Braze™ Pd 484 | 20 | 52 | 28 | - | - | 875-900 | - | PD102 | Pd 484 V1 | ViewMeta-Braze™ Pd 484Meta-Braze™ Pd 484 is a palladium-silver-copper brazing filler metal which is used in a wide range of applications including vacuum tube devices and electronic components. It can also be used to produce joints for moderately high (300-400°C) elevated temperature service conditions where it exhibits good oxidation resistance coupled with good elevated-temperature mechanical properties. Product Forms× |
| Meta-Braze™ Pd 587 | 25 | 54 | 21 | - | - | 901-950 | BVAg-32 | PD101 | Pd 587 V1 | ViewMeta-Braze™ Pd 587Meta-Braze™ Pd 587 is a palladium-silver-copper brazing filler metal which is used in a wide range of applications including vacuum tube devices, electronic components and aerospace components. It can also be used to produce joints for moderately high (300-400°C) elevated temperature service conditions where it exhibits good oxidation resistance coupled with good elevated-temperature mechanical properties. Product Forms× |
| Meta-Braze™ Pd 288 | 5 | 95 | - | - | - | 970-1010 | - | PD204 | Pd 288 V1 | ViewMeta-Braze™ Pd 288Meta-Braze™ Pd 288 is a palladium-silver alloy that is good for brazing nickel, stainless steel and refractory metals. Product Forms× |
| Meta-Braze™ Pd 483 | 18 | - | 82 | - | - | 1080-1090 | - | PD203 | Pd 483 V1 | ViewMeta-Braze™ Pd 483Meta-Braze™ Pd 483 is a high purity palladium-copper alloy that is used in specialised aerospace applications. Product Forms× |
| Meta-Braze™ Pd 485 | 20 | 75 | - | - | 5 Mn | 1000-1120 | - | - | Pd 485 | ViewMeta-Braze™ Pd 485Meta-Braze™ Pd 485 is an alloy that is not in common use. It has been used for brazing of superalloys and tungsten carbide in the past. This alloy has limited availability however.× |
| Meta-Braze™ Pd 030 | 30 | 70 | - | - | - | 1150-1225 | - | - | - | ViewMeta-Braze™ Pd 030Meta-Braze™ Pd 030 is a high temperature palladium-silver alloy that can be used for brazing for brazing nickel, stainless steel and refractory metals. Product Forms× |
| Meta-Braze™ Pd 647 | 60 | - | - | 40 | - | 1235 | - | PD201 | Pd 647 V1 | ViewMeta-Braze™ Pd 647Meta-Braze™ Pd 647 is a very high temperature palladium-nickel alloy that is typically used when there is a requirement for an alloy which exhibits high temperature strength and resistance to chemical attack at elevated temperatures. Product Forms× |
| Meta-Braze™ Pd 047 | 46.7 | - | - | 47.2 | 6.1 Si | 851 | - | - | - | ViewMeta-Braze™ Pd 047Meta-Braze™ Pd 047 is a specialised palladium-nickel-silicon alloy that available as a melt-spun foil and is used for brazing PCD faced tungsten carbide for oil and gas drilling applications. Product Forms× |
| Meta-Braze™ Pd 065 | 65 | - | - | - | 35 Co | 1219 | BVPd-1 | - | - | ViewMeta-Braze™ Pd 065Meta-Braze™ Pd 065 is a high temperature palladium-cobalt alloy that has high strength and exhibits good wetting on stainless steel and refractory metals. This alloy conforms to AWS A5.8 BPd-1. Product Forms× |
