Solda-Met™ 100
Pure tin can be used for pre-tinning, for adding to solder baths as a solder in its own right.
Lead-Free Soft Solders
Need a solder pre-form?
We can provide solder rings, washers and other pre-formed shapes. Some pre-forms can be made with a flux core, eliminating the need for a separate fluxing operation.
Product Uses and Applications
Lead-free solders are widely specified for their elevated strength and resistance to creep at temperature. They are also obligatory for components where compliance with EU RoHS, EVL, WEEE Directives and other environmental regulations are a factor.
| Key Products | Sn | Ag | Cu | Sb | Melting Range °C | EN29453 | ISO 9453:2014 | Product Info |
|---|---|---|---|---|---|---|---|---|
| Solda-Met™ 100 | 100 | - | - | - | 232 | - | - | View |
| Solda-Met™ 96S | 96 | 4 | - | - | 221-228 | Alloy No.28 | Alloy No.701 | ViewSolda-Met™ 96SSolda-Met™ 96S is a lead-free, tin-silver solder with a short melting range. It is relatively strong and has a melting point approximately 40°C higher than common tin-lead alloys. Solda-Met™ 96S exhibits superior wetting on stainless steel than many other solders and provides a good colour match for stainless also. This alloy is available with an acid core suitable for soldering stainless steel, steel and copper alloys. Product FormsDownloads× |
| Solda-Met™ 965S | 96.5 | 3.5 | - | - | 221 | - | Alloy No.703 | ViewSolda-Met™ 965SProduct FormsDownloads× |
| Solda-Met™ 96SA | 96.15 | 3.5 | - | 0.35 | 221 | - | - | ViewSolda-Met™ 96SAProduct Forms× |
| Solda-Met™ 975S | 97.5 | - | 2.5 | - | 221-225 | - | - | ViewSolda-Met™ 975SProduct Forms× |
| Solda-Met™ 97C | 97 | - | 3 | - | 230-250 | Alloy No.24 | Alloy No.402 | ViewSolda-Met™ 97CProduct FormsDownloads× |
| Solda-Met™ 99C | 99.3 | - | 0.7 | - | 230-240 | Alloy No.23 | Alloy No.401 | ViewSolda-Met™ 99CProduct FormsDownloads× |
| Solda-Met™ 95A | 95 | - | - | 5 | 230-240 | Alloy No.18 | Alloy No.201 | ViewSolda-Met™ 95AProduct Forms× |
| Solda-Met™ 87SC | 87 | 10 | 3 | - | 214-275 | - | - | ViewSolda-Met™ 87SCProduct FormsDownloads× |
